Block Storage Feature Details
Flexible, resilient block storage for your private cloud — powered by Ceph and NVMe.
Block Storage – 3 Ways, Same System
Block storage is available by default to your virtual machines (VMs) or containers from within your private Cloud Core. In addition to the default, there are several options that you can take advantage of depending on the performance, cost per GB, or data redundancy levels you need. Since this is a fully private cloud with your own control plane, you can modify OpenStack Cinder or Ceph to fit your needs.
Highly Available Network Block Storage
All private Cloud Cores come by default with Ceph configured to provide block storage that is backed by a triplicate copy of your data. Each server has at least 1 drive that is within a Ceph pool. The pool is then made available by Ceph to OpenStack for your VMs or containers to mount as block storage.
In the event a server or drive becomes unavailable, your Ceph and the block storage will continue to work for your VMs using that storage. With network block storage, live migration, the ability to move VMs between hardware nodes with 1 or 2 ping drops, is supported.
Single Drive High IOPS NVMe Block Storage
On Cloud Cores with more than 1 workload drive or on additional servers added to your cluster, you can choose the configuration of those additional drives. A popular choice to get the most speed out of your NVMe drives is to use a single drive directly.
In this scenario, there is no redundancy, and so redundancy, if needed, would be handled at the software layer. A replicated database, Galera for example, runs great when it has high IOPS and handles its own replication on other single drive backed VMs.
RAID 1 High IOPS NVMe Block Storage
A variation of the single drive high IOPS NVMe block storage, the addition of a software RAID 1 above 2 drives brings in drive level redundancy with a small write penalty and a potential increase in read speeds.
Resilient and Scalable Block Storage
Achieve maximum flexibility while your cloud applications can scale on demand.
Highly Available
Suitable for performance-sensitive scenarios and allows you to scale to very serious workloads.
Component-Based Architecture
Quickly add new behaviors and increase the size of your block storage volume at any time.
Enterprise Class Performance
HDDs and NVMe drivers maximize performance, higher throughput, and latency, and lower your TCO.
Fault Tolerant
Failures are specifically designed against with a Ceph backed network block storage.
Network Block Storage from Ceph
All 3 servers provide one or more drivers, OSDs, joined into your hyper-converged Ceph cluster. The cluster replicates your data 3 times for data security and operational availability. Your cluster is considered highly available as it can continue serving as normal in the event that 1 cluster member or OSD fails. The performance of your block storage depends on if you have selected NVMe or SATA SSD for your private cloud core. Utilize your management dashboard to create VMs or containers while managing storage devices through API management.
Adding Block Storage to Your Private Cloud Core
In addition to what is provided from your initial private cloud core, you have several options for growing your block storage capacity:
Grow by adding a matching converged node that will increase your block storage, VM, and container capacity.
Create a separate storage cluster that can have different hardware and Ceph settings. The storage blended offers a balance of performance for both block and object storage. The storage large is typically for low-cost object storage but may be a good fit for block storage if write speeds do not need to be high.
With an agreement, a private Cloud Core Large can have additional disks added to the hardware and joined into the Ceph cluster.
Get Started With OpenMetal Cloud
An on-demand private cloud is just seconds away. Create a free account to test drive a cloud and more.
Launch Your Private Cloud
Provision OpenStack powered private clouds on demand. Go from zero to new VMs in about 45 seconds.
Test Drive/Proof of Concept Credits
Migrating a large deployment or pricing out a new project? Test drives and proof of concept credits available now!
Need Help?
Discuss your infrastructure requirements with the OpenMetal cloud team to get a personalized assessment.
Block Storage FAQs
What is Ceph Block Storage?
Ceph provides the network storage including block storage, object storage, and, if needed, an NFS compatible file storage called CephFS. All OpenMetal clouds come with Ceph-based block and object storage supplied by the private Cloud Core.
How do I get help with Ceph or other software from OpenMetal?
In addition to our complimentary, paid, and self-guided training, your account manager can also connect you with skilled resources in the Ceph open source community. Options include support levels appropriate for small, medium, and large customers.
How does Ceph work on OpenMetal Cloud?
Each Cloud Core comes with Ceph pre-configured across your 3-server cluster. Ceph manages the storage pool, replicating your data three times for redundancy and high availability. It integrates natively with OpenStack Cinder to provide block volumes and with OpenStack Swift/S3 for object storage.
Can I use the boot drive for data storage or part of a Ceph pool?
The boot drive is reserved for the operating system and core services. Data storage and Ceph pools use the dedicated workload drives in your Cloud Core. This separation ensures system stability and optimal performance for both the control plane and your storage workloads.
